EXCEPTIONAL QUIET, SUPERIOR FEATURES Pure Power 12 M 1200W is ATX 3.1 compliant and PCIe 5.1 compatible and offers peerless dependability with best-in-class features. Having both a PCIe 5.1 cable and PCIe 6+2 cables in the scope of delivery, this PSU offers outstanding compatibility with current-gen and next-gen graphics cards. Pure Power 12 M 1200W offers the best combination of features in its class.
Produktbeskrivelse
be quiet! Pure Power 12 M 1200W - strømforsyning - 1200 watt
Enhedstype
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse
ATX12V 3.0/ EPS12V 2.92
80 PLUS certificering
80 PLUS Gold
Vægt
1.92 kg
Lokalisering
Europa
Indgangspænding
AC 110-240 V
Udgangspænding
+3.3, +5, ±12 V
Strømkapacitet
1200 watt
Output Current
+3.3V - 22 A +5V - 22 A +12V1 - 55 A +12V2 - 50 A -12V - 0.3 A +5VSB - 3 A
Output-stikforbindelser
1 x strøm 24 pin ATX med aftagelig 4 pin sektion 1 x 12VHPWR 4 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion 1 x strøm 8 pin +12 V med aftagelig 4 pin sektion 1 x strøm 8 pin EPS12 V 6 x 15 pin Serial ATA strøm 2 x 4-PIN intern strøm
Modulær Kabel Administration
Ja
Kølesystem
120 mm ventilator
Udstyr inkluderet
Kabelbånd, skruer
Farve
Sort
Dimensioner (B x D x H)
15 cm x 16 cm x 8.6 cm
Miljømæssige standarder
ENERGY STAR
Producentgaranti
10-års garanti
Generelt
Enhedstype
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse
ATX12V 3.0/ EPS12V 2.92
PSU formfaktor
ATX
Farve
Sort
Lokalisering
Europa
Strømenhed
Indgangspænding
AC 110-240 V
Nødvendig frekvens
50 - 60 Hz
Detaljer om strømudgangskonnektorer
1 x strøm 24 pin ATX med aftagelig 4 pin sektion 1 x 12VHPWR 4 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion 1 x strøm 8 pin +12 V med aftagelig 4 pin sektion 1 x strøm 8 pin EPS12 V 6 x 15 pin Serial ATA strøm 2 x 4-PIN intern strøm
Udgangspænding
+3.3, +5, ±12 V
Strømkapacitet
1200 watt
Output Current
+3.3V - 22 A +5V - 22 A +12V1 - 55 A +12V2 - 50 A -12V - 0.3 A +5VSB - 3 A
Effektivitet
72.9% at 2% Load (230 VAC), 89% at 10% Load (230 VAC), 92.7% at 20% Load (230 VAC), 93.7% at 50% Load (230 VAC), 91.5% at 100% Load (230 VAC)
Strømfaktor (PF)
0.98
Modulær Kabel Administration
Ja
80 PLUS certificering
80 PLUS Gold
Diverse
Udstyr inkluderet
Kabelbånd, skruer
MTBF (forventet tid mellem fejl)
100,000 timer
Kølesystem
120 mm ventilator
Egenskaber
Dobbelt 12V skinner, fuld modulær, LLC resonant konverteringsteknologi, Modern Standby-kompatibel, riffelleje-køleblæser, beskyttelse mod overophedning, beskyttelse mod overstrøm, overbelastningsbeskyttelse, kortslutnings beskyttelse, overspændingsbeskyttelse, beskyttelse mod underspænding, spændings- og tilstrømningsbeskyttelse
