Vigor 4812-11/5FS Endoskop Probe Ø 4.9 mm 1 m

Application:
Diagnosis and documentation of cavities for damage assessment
Improved level of detail thanks to two cameras (90° and 180°) with HD resolution
5-piece set in plastic case:
Basic unit 4812-11G
HD probe 4812-11FS
⌀ 4.9 mm, semi-flexible
SD card 32 GB
Micro HDMI cable (A to D) 1.8 m
USB-C cable (A to C) 1 m
USB-C cable (A to C) 1 m
90 mm (3.5 inch) large reduced-reflection LCD screen (320 x 240 pixels)
Luminous source: 5 dimmable (10-stage) LED for optimum lighting
Light intensity: front LED 200 – 300 Lux, side LED 550 – 700 Lux (measured at 5 cm distance)
Optional recording in different time loops (5 ∙ 10 ∙ 15 ∙ 20 minutes)
Zoom: 1.5 x and 2 x
Image format (Jpeg): 1920 x 1080 pixels
Video format (MP4): 1920 x 1080 pixels
Mirroring of the camera image
Negative display of the camera image (better detection of damaged areas)
Data transfer: USB-C
Video output: micro HDMI
Operating temperature: 10° C to 50° C
Operating humidity of up to 90 % (non-condensing)
IP protection rating (basic unit): IP54
Compatible with HAZET HD probes 4812-11FS and 4812-23AF
Energy source: 4 x battery AA
USB interface can be used as a power source when no batteries are inserted
Weight: 370 grams without batteries
Dimensions (L x W x H): 276 x 123 x 54 mm
Compact design
Easy to handle
Eyelet on the battery compartment for mounting a hand strap (drop guard)
Thread for mounting a tripod screw connection (1/4")
Reset button
Auto power-off function, 3-way adjustable (Off ∙ 5 ∙ 10 minutes)
Record videos (MOV format) and photos (JPEG format)
Image format: Jpeg, 1920 x 1080 pixels with optional timestamp
Video format: MP4, 1920 x 1080 pixels with optional timestamp
29 different menu languages can be selected
Use of the system as a card reader / camera via USB connection to PC
Compatible with HAZET HD probes 4812-11FS and 4812-23AF
Current software on this item can be found at hazet.de → Software & spare parts → Downloads
