Allied Telesis IE220-10GHX, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Wall mountable

Item no.: [10464998] | Manufacturer: Allied Telesyn International | Model no.: AT-IE220-10GHX-80 | EAN: 0767035226392

out of stock

The item is not in stock. More info

Varen er ikke på lager.

Brug funktionen ”Giv mig besked..." herunder for opdateringer.

Shipping @price - GLS

12,00

EUR 1.007,86

Incl. VAT 1.259,83

Total incl. delivery 1.274,83

Notify me when the item is in stock again

Read further specifications and description

Industrial Ethernet Layer 2+ PoE++ Switches with 10G uplinks
Ruggedized switches built for enduring performance in harsh environments. Power over Ethernet (PoE++) connects and powers environmental, system control, and other key IIoT devices for a reliable and high-performing solution and 10G fiber uplinks ensure capacity for demanding edge applications. The IE220 Series enables safety, security, and smooth operation for building automation, intelligent transportation, and smart city networks.

Produktbeskrivelse	Allied Telesis AT IE220-10GHX - switch - 10 porte - Administreret
Enhedstype	Switch - 10 porte - L2+ - Administreret
Undertype	Gigabit Ethernet
Porte	8 x 10/100/1000Base-T + 2 x 1 Gigabit / 10 Gigabit SFP+ (uplink)
Power Over Ethernet (PoE)	PoE++
PoE-budget	240 W
Præstation	Skift af stofbåndbredde: 56 Gbps Videresendelseshastighed: 41.7 Mpps
Kapacitet	Bufferkapacitet (MB): 2 Prioritetskøer: 8 Samtidige VLANs: 4000 Multicast-grupper: 1023
MAC adresse table størrelse	16K indtastningshukommelse
Jumborammesupport	12KB
Routingprotokol	IGMPv2, IGMP, statisk IP routing, IGMPv3, MLDv2, MLD, MSTP, RSTP, STP
Protokol til fjernadministration	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, NETCONF, RESTCONF, DHCP, YANG, Syslog, MIB
Egenskaber	Datatransport, DiffServ understøttet, strømstødsbeskyttelse, sFlow, DHCP snooping, ACL support, QoS, DAI, PVST+, nulstillingsknap, UDLD, blæserløs, LACP, RSPAN, DoS, OpenFlow support, EPSRing, sort hul-routing, SCP, BIST, Cable fault locator (TDR), SDN, DDM, Active Fiber Monitoring, AAA, VLAN-spejling, CFM, stormbeskyttelse, LAG, MRP, BPDU-beskyttelse, LLDP-MED, IP Directed Broadcast, CCP, UFO
Overensstemmelsesstandarder	IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ag, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.3bt
Dimensioner (B x D x H)	15.5 cm x 13.7 cm x 6.5 cm
Systemkrav	AlliedWare Plus
Producentgaranti	5 års garanti

Generelt
Enhedstype	Switch - 10 porte - L2+ - Administreret
Pakningstype	DIN monterbar på skinne, væg-monterbar
Undertype	Gigabit Ethernet
Porte	8 x 10/100/1000Base-T + 2 x 1 Gigabit / 10 Gigabit SFP+ (uplink)
Power Over Ethernet (PoE)	PoE++
PoE-budget	240 W
Præstation	Skift af stofbåndbredde: 56 Gbps Videresendelseshastighed: 41.7 Mpps
Kapacitet	Bufferkapacitet (MB): 2 Prioritetskøer: 8 Samtidige VLANs: 4000 Multicast-grupper: 1023
MAC adresse table størrelse	16K indtastningshukommelse
Jumborammesupport	12KB
Routingprotokol	IGMPv2, IGMP, statisk IP routing, IGMPv3, MLDv2, MLD, MSTP, RSTP, STP
Protokol til fjernadministration	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, NETCONF, RESTCONF, DHCP, YANG, Syslog, MIB
Krypterings algoritme	DES, RSA, MD5, SSL, TLS, SHA-1, PEAP, TTLS, SHA-2, TLS 1.2, 3DES
Autentificeringsmetode	Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Egenskaber	Datatransport, DiffServ understøttet, strømstødsbeskyttelse, sFlow, DHCP snooping, ACL support, QoS, DAI, PVST+, nulstillingsknap, UDLD, blæserløs, LACP, RSPAN, DoS, OpenFlow support, EPSRing, sort hul-routing, SCP, BIST, Cable fault locator (TDR), SDN, DDM, Active Fiber Monitoring, AAA, VLAN-spejling, CFM, stormbeskyttelse, LAG, MRP, BPDU-beskyttelse, LLDP-MED, IP Directed Broadcast, CCP, UFO
Overensstemmelsesstandarder	IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ag, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.3bt
RAM	512 MB DDR SDRAM
Flashhukommelse	128 MB
Statusindikatorer	PoE, link/aktivitet, fejl, strøm 1, strøm 2
Ekspansion / Konnektivitet
Interface	4 x 1000Base-T RJ-45 PoE+ - 30 W 4 x 1000Base-T RJ-45 PoE++ - 60 W 2 x 1000Base-X/10GBase-X SFP+ uplink 1 x seriel (konsol) RJ-45 administration 1 x USB 2.0 Type A 1 x alarm 3-pins terminalblok
Effekt
Strømenhed	Intern strømforsyning
Egenskaber	Redundant Power System (RPS) konnektor
Diverse
Udstyr inkluderet	Monteringssæt
Overensstemmelsesstandarder	UL, VCCI, ICES-003 Klasse A, UL 2043, FCC, RoHS, WEEE, IEC 60068-2-27, IEC 60068-2-6, ICES, REACH, IEC 60068-2-31, IP30, VCCI Class A, NEMA TS-2, China RoHS, RCM, IEC 60950-22, TSCA, FCC CFR47 Part 15 B Class A, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 61000-4-29, AS/NZS CISPR 32 Class A, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 55032 Class A, CISPR 32 Class A, ITU-T G.8032, EN 55035, IEC/EN/UL 62368-1, IEC/EN 61000-3-3, EN 60715, EN 50021, IEC 62439-2, AS/NZS 62368-1, TEC, IEC 60512-99-002, UKCA, SCIP, UL/CSA 62368-1, EN IEC 61000-3-2
Programmer / Systemkrav
OS nødvendig	AlliedWare Plus
Mål og vægt
Bredde	15.5 cm
Dybde	13.7 cm
Højde	6.5 cm
Producentgaranti
Service & Support	Begrænset garanti - 5 år
Miljømæssige parametre
Min. driftstemperatur	-40 °C
Maks. driftstemperatur	75 °C
Fugtighedsgrad ved brug	5 - 95 % (ikke-kondenserende)
Min. lagertemperatur	-40 °C
Maks. Opbevaringstemperatur	85 °C
Lagerfugtighedsgrad	5 - 95 % (ikke-kondenserende)

The item is known under the following item numbers in our system

EAN:	0767035226392
SKU:	AT-IE220-10GHX-80

Why do I find that the same product is available on different item numbers?

Manufacturers often release the same product with different item numbers, typically just different versions of the packaging. For example, the packaging may be targeted at different countries. We try our best to unify the products, but it can happen that the same product appears on different item numbers in our system.
