The SilentStorm SFX Bronze series is an “80 PLUS Bronze” certified SFX power supply series for users looking for the best price-performance. It offers outstanding efficiency of over 85 percent under 50 percent load and meets the strict requirements of the independent 80 PLUS Initiative “PLUG LOAD SOLUTIONS” for the Bronze certificate. The compact dimensions total to only 125 x 100 x 63 mm. Power supplies can be installed into conventional ATX cases using the enclosed ATX mounting frame.
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse
SFX12V 3.2
80 PLUS certificering
80 PLUS Bronze
Vægt
1 kg
Indgangspænding
AC 100-240 V
Strømkapacitet
450 Watt
Output Current
+5V - 22 A +3.3V - 21 A +12V - 36 A -12V - 0.5 A +5VSB - 3 A
Output-stikforbindelser
1 x strøm 24 pin ATX med aftagelig 4 pin sektion 1 x strøm 8 pin +12 V med aftagelig 4 pin sektion 1 x 6 pin PCI Express-strøm 3 x 15 pin Serial ATA strøm 2 x 4-PIN intern strøm 1 x 4-PIN mini-strømforsyningsforbinder 1 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion
Kølesystem
80 mm ventilator
Udstyr inkluderet
Skruer, SFX to ATX bracket, kabelbånd
Farve
Sort
Dimensioner (B x D x H)
12.5 cm x 10 cm x 6.3 cm
Producentgaranti
3 års garanti
Generelt
Enhedstype
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse
SFX12V 3.2
PSU formfaktor
SFX
Farve
Sort
Strømenhed
Indgangspænding
AC 100-240 V
Nødvendig frekvens
50 - 60 Hz
Detaljer om strømudgangskonnektorer
1 x strøm 24 pin ATX med aftagelig 4 pin sektion 1 x strøm 8 pin +12 V med aftagelig 4 pin sektion 1 x 6 pin PCI Express-strøm 3 x 15 pin Serial ATA strøm 2 x 4-PIN intern strøm 1 x 4-PIN mini-strømforsyningsforbinder 1 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion
Strømkapacitet
450 Watt
Output Current
+5V - 22 A +3.3V - 21 A +12V - 36 A -12V - 0.5 A +5VSB - 3 A
Effektivitet
85 % ved 50 % ladning, 82 % ved 20 % ladning, 82 % ved 100 % ladning
80 PLUS certificering
80 PLUS Bronze
Diverse
Udstyr inkluderet
Skruer, SFX to ATX bracket, kabelbånd
Medfølgende ledninger
Strømkabel - ekstern
MTBF (forventet tid mellem fejl)
50,000 timer
Kølesystem
80 mm ventilator
Egenskaber
Intel 4.-gen CPU (Haswell) kompatibel, overspændingsbeskyttelse, beskyttelse mod underspænding, kortslutnings beskyttelse, overbelastningsbeskyttelse, ikke-modulær
Overensstemmelsesstandarder
ERP, FCC, C-Tick, BSMI, CB
Producentgaranti
Service & Support
Begrænset garanti - 3 år
Miljømæssige parametre
Min. driftstemperatur
0 °C
Maks. driftstemperatur
40 °C
Lydudbredelse
30 dBA
Mål og vægt
Bredde
12.5 cm
Dybde
10 cm
Højde
6.3 cm
Vægt
1 kg
Mål & vægt (forsendelse)
Bredde ved forsendelse
23 cm
Dybde ved forsendelse
19 cm
Højde ved forsendelse
8 cm
Vægt ved forsendelse
1.5 kg
Vægt (gram)
1449
GPSR
Sharkoon Technologies GmbH Grüninger Weg 48 35415 Pohlheim DE [email protected] https://de.sharkoon.com/
