High efficiency and a highly competitive pricing coupled with the latest “state-of-the-art” PCB design and components distinguish the 6 new power supplies of the iARENA series. Fully aware of environmental requirements, CHIEFTEC offers European PC manufacturers a solution, fixed @230V and with reduced procurement costs thanks to the resource-friendly bulk packaging.
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse
ATX12V 2.3/ PS/2
80 PLUS certificering
80 PLUS Bronze
Indgangspænding
AC 230 V
Udgangspænding
+3.3, +5, ±12 V
Strømkapacitet
350 watt
Output Current
+5V - 15 A +3.3V - 16 A +12V1 - 26 A -12V - 0.3 A +5VSB - 2.5 A
Output-stikforbindelser
1 x strøm 24 pin ATX med aftagelig 4 pin sektion 1 x effekt ATX12V 4-pin stik 5 x 15 pin Serial ATA strøm 3 x 4-PIN intern strøm 1 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion
Kølesystem
120 mm ventilator
Dimensioner (B x D x H)
15 cm x 14 cm x 8.7 cm
Producentgaranti
2 års garanti
Generelt
Enhedstype
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse
ATX12V 2.3/ PS/2
PSU formfaktor
ATX
Strømenhed
Indgangspænding
AC 230 V
Indgangspændingsområde
AC 200 - 240 V
Nødvendig frekvens
47 - 63 Hz
Detaljer om strømudgangskonnektorer
1 x strøm 24 pin ATX med aftagelig 4 pin sektion 1 x effekt ATX12V 4-pin stik 5 x 15 pin Serial ATA strøm 3 x 4-PIN intern strøm 1 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion
Udgangspænding
+3.3, +5, ±12 V
Strømkapacitet
350 watt
Output Current
+5V - 15 A +3.3V - 16 A +12V1 - 26 A -12V - 0.3 A +5VSB - 2.5 A
80 PLUS certificering
80 PLUS Bronze
Diverse
Kølesystem
120 mm ventilator
Egenskaber
Overspændingsbeskyttelse, overbelastningsbeskyttelse, beskyttelse mod underspænding, kortslutnings beskyttelse, blæserhastighedsstyring, ikke-modulær
Overensstemmelsesstandarder
TUV, CB, RoHS, EuP Ready
Producentgaranti
Service & Support
Begrænset garanti - 2 år
Mål og vægt
Bredde
15 cm
Dybde
14 cm
Højde
8.7 cm
