Schneider Electric PM5110, Domestic, Power current, Power factor, Power frequency, Voltage, Black, LCD, Flush-mounted, Square
Item no.: [1528181] | Manufacturer: SCHNEIDER ELECTRIC | Model no.: METSEPM5110 | EAN: 3606480613982 | UNSPSC.: 41113630 | EL-nr.: 3398516478
Remote stock (1-2 days)
The item is in a remote warehouse, delivery time is 1-2 business days. More info
Delivery options - Select at checkout
Shipping @price - GLS
12,00
EUR
528,87
Incl. VAT 661,09
Total incl. delivery
676,09
The function requires that you are logged in. Create a user and use our smart list system to keep track of future purchases, regular purchases or wish lists. Create user Login
SCHNEIDER ELECTRIC POWERLOGIC PM5110 3V X/5A LK0.5S PAN
Application
Domestic
Measuring functions
Power current, Power factor, Power frequency, Voltage
Product colour
Black
Display type
LCD
Mounting type
Flush-mounted
Shape
Square
Number of phases
3
Connector(s)
RS485
International Protection (IP) code
IP54, IP30
Supported protocols
Modbus RTU and ASCII 9.6, 19.2 and 38.4 kbaud Even/Odd or none 2 wires 2500 VJBUS
Certification
CE IEC 61010-1CULus UL 61010-1
Power source type
AC
Maximum current
8.5 A
Input voltage
90 - 450 V
Rated current
5 A
AC input frequency
45 - 65 Hz
Operating temperature (T-T)
25 - 70 °C
Storage temperature (T-T)
40 - 85 °C
Operating relative humidity (H-H)
5 - 95%
Operating altitude
0 - 2000 m
Width
96 mm
Depth
72 mm
Height
96 mm
Weight
380 g
Package weight
449 g
Package depth
129.7 mm
Package width
125.4 mm
Package height
114.6 mm
