NZXT C750, 750 W, 115 - 240 V, 50/60 Hz, 10 - 5 A, 10 A, 5 A

Item no.: [20062653] | Manufacturer: NZXT | Model no.: PA-7B2BB-EU | EAN: 5056547203591

Remote stock (2-3 days)

The item is in a remote warehouse, delivery time is 2-3 business days. More info

Shipping @price - GLS

12,00

EUR 57,33

Incl. VAT 71,66

Total incl. delivery 86,66

Read further specifications and description

The C-Series power supply from NZXT features safe, reliable power while ensuring optimal efficiency and quieter performance. Manufactured with high-quality components, the C-Series power supplies deliver both peace of mind and clean, reliable power to your PC gaming system. The modular design lets you use only the cables you need, ensuring easier installation, and less clutter. The sleeved main cables look great and resist heat damage as well as fraying, delivering greater durability and longevity.

Produktbeskrivelse	NZXT C-Series C750 - strømforsyning - 750 Watt
Enhedstype	Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse	ATX12V 2.4/ EPS12V 2.92
80 PLUS certificering	80 PLUS Bronze
Lokalisering	Europa
Indgangspænding	AC 115/230 V
Udgangspænding	+3.3, +5, ±12 V
Strømkapacitet	750 Watt
Output Current	+3.3V - 20 A +5V - 20 A +12V - 62.5 A -12V - 0.3 A +5VSB - 2.5 A
Output-stikforbindelser	1 x strøm 24 pin ATX 2 x strøm 8 pin EPS12 V med aftagelig 4 pin ATX12V sektion 6 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion 6 x 15 pin Serial ATA strøm 3 x 4-PIN intern strøm
Modulær Kabel Administration	Ja
Kølesystem	120 mm ventilator
Udstyr inkluderet	4 skruer
Farve	Mat sort
Dimensioner (B x D x H)	15 cm x 14 cm x 8.6 cm
Producentgaranti	5 års garanti

Generelt
Enhedstype	Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse	ATX12V 2.4/ EPS12V 2.92
PSU formfaktor	ATX
Farve	Mat sort
Lokalisering	Europa
Strømenhed
Indgangspænding	AC 115/230 V
Nødvendig frekvens	47 - 63 Hz
Detaljer om strømudgangskonnektorer	1 x strøm 24 pin ATX 2 x strøm 8 pin EPS12 V med aftagelig 4 pin ATX12V sektion 6 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion 6 x 15 pin Serial ATA strøm 3 x 4-PIN intern strøm
Udgangspænding	+3.3, +5, ±12 V
Strømkapacitet	750 Watt
Output Current	+3.3V - 20 A +5V - 20 A +12V - 62.5 A -12V - 0.3 A +5VSB - 2.5 A
Effektivitet	83% at 20% Load, 87% at 50% Load, 82% at 10% Load, 83% at 100% Load
Strømfaktor (PF)	0.96
Modulær Kabel Administration	Ja
80 PLUS certificering	80 PLUS Bronze
Diverse
Udstyr inkluderet	4 skruer
MTBF (forventet tid mellem fejl)	100,000 timer
Kølesystem	120 mm ventilator
Egenskaber	Køleblæser til flydende dynamisk leje, semi-modulær
Overensstemmelsesstandarder	TUV, BSMI, CB, CCC, FCC, RoHS, WEEE, EAC, China RoHS, RCM, cTUV, UKCA
Producentgaranti
Service & Support	Begrænset garanti - 5 år
Miljømæssige parametre
Min. driftstemperatur	0 °C
Maks. driftstemperatur	40 °C
Lydudbredelse	32.3 dBA
Mål og vægt
Bredde	15 cm
Dybde	14 cm
Højde	8.6 cm

The item is known under the following item numbers in our system

EAN:	5056547203591
SKU:	PA-7B2BB-EU

Why do I find that the same product is available on different item numbers?

Manufacturers often release the same product with different item numbers, typically just different versions of the packaging. For example, the packaging may be targeted at different countries. We try our best to unify the products, but it can happen that the same product appears on different item numbers in our system.
