The ZALMAN GigaMax III ZM850-GV3 power supply is designed to meet the needs of demanding PC/Server configurations, offering 850 watts of power with an 80 PLUS Bronze certification for efficient energy use. It features a 120 mm cooling fan with fluid dynamic bearing technology, ensuring quiet operation and effective cooling. With active Power Factor Correction (PFC) and DC-DC technology, it provides stable and reliable power delivery. The power supply is equipped with comprehensive protection features, including overcurrent, overpower, overvoltage, short-circuit, thermal, and undervoltage protection, safeguarding your system under various conditions. Its compatibility with CrossFire and SLI configurations makes it a suitable choice for multi-GPU setups, while a variety of power output connectors ensure wide compatibility with different PC/Server configurations. Whether you're building a new system or upgrading an existing one, the ZALMAN GigaMax III ZM850-GV3 offers the performance and reliability you need.
Produktbeskrivelse
ZALMAN GigaMax III ZM850-GV3 - strømforsyning - 850 Watt
Enhedstype
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse
ATX12V 3.0
80 PLUS certificering
80 PLUS Bronze
Vægt
1.8 kg
Indgangspænding
AC 200-240 V
Udgangspænding
+3.3, +5, ±12 V, -12V, +5Vsb V
Strømkapacitet
850 Watt
Output Current
+3.3V - 20 A +5V - 20 A +12V - 70.83 A -12V - 0.3 A +5VSB - 3 A
Output-stikforbindelser
1 x strøm 24 pin ATX med aftagelig 4 pin sektion 1 x strøm 8 pin +12 V med aftagelig 4 pin sektion 2 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion 5 x 15 pin Serial ATA strøm 3 x 4-PIN intern strøm 1 x 4-PIN mini-strømforsyningsforbinder
Kølesystem
120 mm ventilator
Dimensioner (B x D x H)
15 cm x 14 cm x 8.6 cm
Producentgaranti
5 års garanti
Generelt
Enhedstype
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse
ATX12V 3.0
PSU formfaktor
ATX
Strømenhed
Indgangspænding
AC 200-240 V
Nødvendig frekvens
50 - 60 Hz
Detaljer om strømudgangskonnektorer
1 x strøm 24 pin ATX med aftagelig 4 pin sektion 1 x strøm 8 pin +12 V med aftagelig 4 pin sektion 2 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion 5 x 15 pin Serial ATA strøm 3 x 4-PIN intern strøm 1 x 4-PIN mini-strømforsyningsforbinder
Udgangspænding
+3.3, +5, ±12 V, -12V, +5Vsb V
Strømkapacitet
850 Watt
Output Current
+3.3V - 20 A +5V - 20 A +12V - 70.83 A -12V - 0.3 A +5VSB - 3 A
Effektivitet
88% (230VAC)
80 PLUS certificering
80 PLUS Bronze
Diverse
MTBF (forventet tid mellem fejl)
100,000 timer
Kølesystem
120 mm ventilator
Egenskaber
Beskyttelse mod overstrøm, overspændingsbeskyttelse, overbelastningsbeskyttelse, SLI klar, CrossFire klar, beskyttelse mod underspænding, kortslutnings beskyttelse, termisk beskyttelse, DC-DC teknologi, køleblæser til flydende dynamisk leje, ikke-modulær
Overensstemmelsesstandarder
CB, RoHS, KC, EAC, RCM
Producentgaranti
Service & Support
Begrænset garanti - 5 år
Miljømæssige parametre
Min. driftstemperatur
0 °C
Maks. driftstemperatur
40 °C
Mål og vægt
Bredde
15 cm
Dybde
14 cm
Højde
8.6 cm
Vægt
1.8 kg
