The Sharkoon Rebel P20 power supply provides reliable performance for both PC and server setups. With an efficiency rating of 87% at 115 VAC and 89% at 230 VAC, it ensures optimal power usage while keeping the system stable. The fully modular design allows users to customize cable management, reducing clutter inside the case. Equipped with a 120 mm fan featuring a zero RPM fan mode and fluid dynamic bearing, the unit operates quietly while maintaining optimal cooling performance.
Safety is a priority with features such as overcurrent, overvoltage, undervoltage, short-circuit, overload, and overheat protection. With a mean time between failures (MTBF) of 100,000 hours, this power supply is designed for long-lasting use in a variety of environmental conditions. The Sharkoon Rebel P20 supports a range of voltage inputs and outputs, making it compatible with diverse systems and ensuring stable energy delivery.
Produktbeskrivelse
Sharkoon Rebel P20 - strømforsyning - 750 watt
Enhedstype
Strømforsyning - intern
Specifikationsoverensstemmelse
ATX 3.1
Cybenetics-certificering
Cybenetics Gold
Vægt
1.5 kg
Indgangspænding
AC 100-240 V
Udgangspænding
+3.3, +5, ±12 V, +5Vsb V
Strømkapacitet
750 watt
Output Current
+3.3V - 20 A +5V - 20 A +12V - 70.8 A -12V - 0.3 A +5VSB - 3 A
Output-stikforbindelser
1 x strøm 24 pin ATX 2 x strøm 4+4 pin 4 x 8 (6+2) pin strøm 11 x 15 pin Serial ATA strøm 1 x 12V 2x6
Modulær Kabel Administration
Ja
Kølesystem
120 mm ventilator
Udstyr inkluderet
Modulære kabler, skruer
Farve
Sort
Dimensioner (B x D x H)
14 cm x 15 cm x 8.6 cm
Producentgaranti
7 års garanti
Generelt
Enhedstype
Strømforsyning - intern
Specifikationsoverensstemmelse
ATX 3.1
PSU formfaktor
ATX
Farve
Sort
Strømenhed
Indgangspænding
AC 100-240 V
Nødvendig frekvens
50 - 60 Hz
Detaljer om strømudgangskonnektorer
1 x strøm 24 pin ATX 2 x strøm 4+4 pin 4 x 8 (6+2) pin strøm 11 x 15 pin Serial ATA strøm 1 x 12V 2x6
Udgangspænding
+3.3, +5, ±12 V, +5Vsb V
Strømkapacitet
750 watt
Output Current
+3.3V - 20 A +5V - 20 A +12V - 70.8 A -12V - 0.3 A +5VSB - 3 A
Effektivitet
87% (115VAC), 89% (230VAC)
Modulær Kabel Administration
Ja
Cybenetics-certificering
Cybenetics Gold
Diverse
Udstyr inkluderet
Modulære kabler, skruer
Medfølgende ledninger
Strømkabel
MTBF (forventet tid mellem fejl)
100,000 timer
Kølesystem
120 mm ventilator
Egenskaber
Zero RPM-blæsermodus, køleblæser til flydende dynamisk leje, beskyttelse mod overstrøm, overspændingsbeskyttelse, beskyttelse mod underspænding, kortslutnings beskyttelse, overbelastningsbeskyttelse, beskyttelse mod overophedning, fuld modulær
Overensstemmelsesstandarder
ERP, CB, FCC, RoHS, REACH
Producentgaranti
Service & Support
Begrænset garanti - 7 år
Miljømæssige parametre
Min. driftstemperatur
0 °C
Maks. driftstemperatur
40 °C
Mål og vægt
Bredde
14 cm
Dybde
15 cm
Højde
8.6 cm
Vægt
1.5 kg
