Teltonika SWM280, Managed, L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting

Item no.: [24815084] | Manufacturer: Teltonika | Model no.: SWM280000000 | EAN: 4779051844074

Remote stock (4-5 days)

The item is in a remote warehouse, delivery time is 3-4 business days. More info

Shipping @price - GLS

12,00

EUR 260,36

Incl. VAT 325,45

Total incl. delivery 340,45

Read further specifications and description

The SWM280 is a powerful L2 managed switch with L3 features for advanced network control. Designed for high-performance connectivity, this 24-port switch combines 12 PoE+ ports, 12 Gigabit Ethernet ports, and 4 SFP ports. The PoE+ supply up to 30 W per port and a total power budget of 300 W. The SWM280 supports PROFINET & other industrial protocols, enabling flexibility over management and power supply.

Produktbeskrivelse	Teltonika SWM280 - switch - 24 porte - Administreret - monterbar på stativ - med 2 års RMS Management
Enhedstype	Switch - 24 porte - L2+ - Administreret - med 2 års RMS Management
Pakningstype	Monterbar på stativ
Undertype	Gigabit Ethernet
Porte	12 x 10/100/1000 (PoE+) + 12 x 10/100/1000 + 4 x SFP
Power Over Ethernet (PoE)	PoE+
PoE-budget	300 W
Præstation	Ikke-blokerende båndbredde: 56 Gbps Videresendelseshastighed: 83,33 Mpps
Kapacitet	Pakkebufferstørrelse: 512 KB
MAC adresse table størrelse	80K indtastningshukommelse
Jumborammesupport	10.000 byte
Routingprotokol	BGP, OSPFv2, RIP-1, RIP-2, EIGRP
Protokol til fjernadministration	SNMP 2, SNMP 3
Egenskaber	QoS, Storm Control, port-baseret formgiving, WFQ, WRR, LLDP support, anodiseret aluminiumskabinet, auto-uplink (auto MDI/MDI-X), løkkebeskyttelse, videresendelsestabel, STP support, RSTP support, DHCP klient, DHCP server, link speed control, portisolering, PoE-administration, portspejling, EEE, PAM, VLAN-segmentering
Overensstemmelsesstandarder	IEEE 802.3af, IEEE 802.3at, IEEE 802.1Q, IEEE 802.1x, IEEE 802.1p, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Effekt	AC 100-240 V (50/60 Hz)
Dimensioner (B x D x H)	48.3 cm x 23.4 cm x 4.4 cm
Vægt	1.842 kg

Generelt
Enhedstype	Switch - 24 porte - L2+ - Administreret - med 2 års RMS Management
Pakningstype	Monterbar på stativ
Undertype	Gigabit Ethernet
Porte	12 x 10/100/1000 (PoE+) + 12 x 10/100/1000 + 4 x SFP
Power Over Ethernet (PoE)	PoE+
PoE-budget	300 W
Præstation	Ikke-blokerende båndbredde: 56 Gbps Videresendelseshastighed: 83,33 Mpps
Kapacitet	Pakkebufferstørrelse: 512 KB
MAC adresse table størrelse	80K indtastningshukommelse
Jumborammesupport	10.000 byte
Routingprotokol	BGP, OSPFv2, RIP-1, RIP-2, EIGRP
Protokol til fjernadministration	SNMP 2, SNMP 3
Autentificeringsmetode	RADIUS, TACACS
Egenskaber	QoS, Storm Control, port-baseret formgiving, WFQ, WRR, LLDP support, anodiseret aluminiumskabinet, auto-uplink (auto MDI/MDI-X), løkkebeskyttelse, videresendelsestabel, STP support, RSTP support, DHCP klient, DHCP server, link speed control, portisolering, PoE-administration, portspejling, EEE, PAM, VLAN-segmentering
Overensstemmelsesstandarder	IEEE 802.3af, IEEE 802.3at, IEEE 802.1Q, IEEE 802.1x, IEEE 802.1p, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Processor	1: 500 MHz
RAM	128 MB DDR3 SDRAM
Flashhukommelse	16 MB
Statusindikatorer	Strøm, SFP, netværk
Ekspansion / Konnektivitet
Interface	12 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W 12 x 10/100/1000 Base-T RJ-45 4 x LAN SFP
Effekt
Strømenhed	Intern strømforsyning
Nødvendig spænding	AC 100-240 V (50/60 Hz)
Strømforbrugs-stand by	7.5 Watt
Diverse
Udstyr inkluderet	Jordningsskrue, strømkabel (C14)
Rackmonteringspakke	Valgfri
Overensstemmelsesstandarder	IP30, UKCA, CB, RCM, FCC, IC, RoHS, REACH
Programmer / Systemkrav
Med software	SwmOS
Mål og vægt
Bredde	48.3 cm
Dybde	23.4 cm
Højde	4.4 cm
Vægt	1.842 kg
Miljømæssige parametre
Min. driftstemperatur	0 °C
Maks. driftstemperatur	50 °C
Fugtighedsgrad ved brug	10 - 90 % (ikke-kondenserende)

The item is known under the following item numbers in our system

EAN:	4779051844074
SKU:	SWM280000000
