The item is in a remote warehouse, delivery time is 2-3 business days. More info
Delivery options - Select at checkout
159,20
EUR
2.784,16
Incl. VAT 3.480,20
Total incl. delivery
3.679,20
The function requires that you are logged in. Create a user and use our smart list system to keep track of future purchases, regular purchases or wish lists. Create user Login
Accelerating Artificial Intelligence and Leading Efficiency Engineering richer features in a revolutionary platform, Intel has made an incredible jump in processor performance in the business transformation journey. AI and deep learning performance will benefit from the built-in AI acceleration engines, while networking, storage, and analytics leverage other specialized accelerators in the 4th & 5th Gen Intel Xeon Scalable processors. Adding a host of new features to target a wide range of workloads, the new families of Intel Xeon processors will deliver even better CPU performance and performance per watt, and do so on a PCIe 5.0 platform with 2x the prior gen throughput to greatly speed up data movement to and from GPUs and storage. Intel also created the Intel Xeon CPU Max Series with High Bandwidth Memory (HBM) for improvements in memory bound HPC and AI workloads. For this new platform, GIGABYTE has products ready to get the most out of Intel Xeon CPU-based systems that support fast PCIe Gen5 accelerators and Gen5 NVMe drives, in addition to support for high performant DDR5 memory.
Built-in processor
No
Motherboard chipset
Intel C741
Processor socket
LGA 4677 (Socket E)
Number of processors supported
2
Compatible processor series
Intel® Xeon®
Number of DIMM slots
32
Supported memory types
DDR5-SDRAM
Memory channels
Octa-channel
Number of storage drives supported
14
Hot-swap HDD bays
Yes
Number of 2.5" bays
14
Storage drive sizes supported
2.5,3.5"
Supported storage drive types
HDD & SSD
Supported storage drive interfaces
Serial ATA, Serial Attached SCSI (SAS)
On-board graphics card model
Aspeed AST2600
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
LAN controller
Intel® I350-AM2
USB 2.0 ports quantity
0
Ethernet LAN (RJ-45) ports
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
Mini DisplayPorts quantity
1
PCI Express slots version
4.0
Trusted Platform Module (TPM)
Yes
Backplanes support
Yes
Chassis type
Rack (2U)
Product colour
Black, Steel
LED indicators
HDD, LAN, Status
On/off switch
Yes
Reset button
Yes
Cooling type
Active
Power supply
1300 W
Number of main power supplies
2
Redundant power supply (RPS) support
Yes
AC input voltage
110 - 240 V
AC input frequency
50/60 Hz
Input current
12 - 8 A
80 PLUS certification
80 PLUS Titanium
Operating temperature (T-T)
10 - 35 °C
Storage temperature (T-T)
40 - 60 °C
Operating relative humidity (H-H)
8 - 80%
Storage relative humidity (H-H)
20 - 95%
Width
438 mm
Depth
815 mm
Height
87.5 mm
Weight
29 kg
Packaging content
1 x R283-S94-AAH12 x CPU heatsinks1 x Mini-DP to D-Sub cable6 x Carriers1 x 2-Section Rail kit
Package width
1082 mm
Package depth
685 mm
Package height
314 mm
