Dahua Technology LM24-A221Y, 60.5 cm (23.8"), 1920 x 1080 pixels, Full HD, LED, Black

Dahua LM24-A221Y



Professional Full HD monitor with high refresh rate and fast response time for smooth images.
The Dahua LM24-A221Y 23.8" (60.5 cm) monitor uses IPS technology with ELED backlighting and offers a resolution of 1920 × 1080 px in a 16 : 9 aspect ratio. With a high refresh rate of 144 Hz and ultra-fast response time of 1 ms (MPRT), it is ideal for dynamic content where the emphasis is on smooth display.
The display features wide viewing angles of 178°/178° (H/V), 1200 : 1 contrast and 250 cd/m² brightness. The colour gamut covers 72% of NTSC and the panel uses 6bit+ FRC technology. The monitor features a matte finish and Flicker-free technology for comfortable long-term viewing.





23.8" IPS panel with Full HD 1920×1080 px resolution
High refresh rate of 144 Hz for smooth display of dynamic content
Ultra-fast 1ms MPRT response time to minimize motion blur
Wide viewing angles of 178°/178° and 1200 : 1 contrast for high-quality display
Universal connectivity with HDMI 1.4 (144 Hz) and VGA (75 Hz) inputs
Narrow bezels with an 85% display aspect ratio for a sleek look
Low power consumption 16.5 W (base), Flicker-free technology
VESA 100 × 100 mm mounting and adjustable tilt -5°/20°





Connectivity and ControlsThe monitor offers 1× HDMI 1.4 input with support for 1920×1080 resolution at 144Hz and 1× VGA input with support up to 75Hz. Control is via joystick and includes an LED status light.
Construction and designLightweight plastic construction with ultra-narrow bezels and plastic stand. Dimensions without bracket are 542.1 × 322.4 × 47.6 mm, weight 2.8 kg. The frames have a width of 2.3/3.6/3.6/16.8 mm.
Operating conditionsThe monitor is designed for 7 days a week, 16 hours a day operation with a lifetime of 30,000 hours. Operating temperature is 0 °C to +40 °C. Power is provided by an external DC 12V/2A adapter.
Package contentsPower adapter, stand, HDMI cable, user manual (QR code), energy label, legal and regulatory information.




BASIC SPECIFICATIONS

Diagonal: 23.8" (60.5 cm)
Resolution: 1920 × 1080 px (Full HD)
Panel Technology: IPS
Refresh rate: 144 Hz
Response: MPRT 1 ms
Brightness: 250 cd/m²
Contrast: 1200 : 1
Colour gamut: 72% NTSC
Viewing Angles: 178°/178° (H/V)
Inputs: 1× HDMI 1.4, 1× VGA
VESA: 100 × 100 mm
Power consumption: 16.5 W (base), 21.2 W (typical), 22 W (max)
Dimensions: 542.1 × 322.4 × 47.6 mm
Weight: 2.8 kg
