New AMD EPYC™ Family of Processors - Same Great SP5 Platform The SP5 socket has reached its pinnacle form with 5th Generation AMD EPYC™ processors. The same successful platform that was shared by AMD EPYC™ 9004 & 8004 series processors is now the same one for AMD EPYC™ 9005 series processors. With up to 192 cores, increased frequencies and cache, this top tier performance platform targets general purpose, cloud native, and technical computing. Building on the advantages of the EPYC™ 9004 series, the new EPYC™ 9005 series adopts the 3nm process with AMD “Zen5” and “Zen5c” core architecture, excelling in both energy efficiency and cost optimization. GIGABYTE has already prepared for this new processor with new servers and updates to existing products for 4th Gen AMD EPYC™ processors.
Built-in processor
No
Motherboard chipset
AMD SoC
Processor socket
Socket SP5
Number of processors supported
1
Compatible processor series
AMD EPYC 9004, AMD EPYC 9005
Number of DIMM slots
12
Supported memory types
DDR5-SDRAM
Memory channels
Dodeca-channel
Number of storage drives supported
3
Hot-swap HDD bays
Yes
Number of 2.5" bays
2
Storage drive sizes supported
2.5,M.2
Supported storage drive types
HDD & SSD
Supported storage drive interfaces
Serial ATA, PCI Express 3.0, Serial Attached SCSI (SAS)-4
SSD form factor
M.2
On-board graphics card model
Aspeed AST2600
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
LAN controller
Intel® I210-AT
USB 2.0 ports quantity
0
Ethernet LAN (RJ-45) ports
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
Mini DisplayPorts quantity
1
PCI Express x16 (Gen 5.x) slots
2
Number of M.2 (M) slots
1
Trusted Platform Module (TPM)
Yes
Chassis type
Rack (1U)
Product colour
Black, Steel
LED indicators
LAN, HDD, SSD, Status
On/off switch
Yes
Reset button
Yes
Cooling type
Active
Heat sink included
Yes
Number of fans
6 fan(s)
Fan diameter
4 cm
Power supply
1300 W
Number of main power supplies
2
Redundant power supply (RPS) support
Yes
Number of redundant power supplies supported
2
Number of redundant power supplies installed
2
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Input current
8 - 12 A
80 PLUS certification
80 PLUS Titanium
Operating temperature (T-T)
10 - 35 °C
Storage temperature (T-T)
40 - 60 °C
Operating relative humidity (H-H)
8 - 80%
Storage relative humidity (H-H)
20 - 95%
Width
438 mm
Depth
520 mm
Height
43.5 mm
Weight
13.1 kg
Packaging content
1 x E163-Z34-AAH1; 1 x CPU heatsink; 1 x Mini-DP to D-Sub cable
Package width
787 mm
Package depth
594 mm
Package height
226 mm
Package weight
15.1 kg
