Trilux 7017951, LED, 4000 K, 5400 lm, IP20, Grey, Silver
Item no.: [25572775] | Manufacturer: Trilux | EAN: 4018242390120
Remote stock (3-5 days)
The item is in a remote warehouse, delivery time is 3-5 business days. More info
Delivery options - Select at checkout
Shipping @price - GLS
12,00
EUR
444,73
Incl. VAT 555,91
Total incl. delivery
570,91
The function requires that you are logged in. Create a user and use our smart list system to keep track of future purchases, regular purchases or wish lists.
Create user
Login
Create user
Login
Send på mail
Luminaire type
Versatile luminaire module for suspended and surface-mounted luminaires. In combination with accessories to be ordered separately, the modules are completed to form individual luminaires or continuous lines with continuous light emission surface for surface-mounted or suspended installation.
Applications
For the attractive lighting of offices, sales areas, exhibition spaces, banks, ticket halls, schools and educational facilities.
Mounting methods
In combination with the accessories to be ordered separately for the desired application, the module is suitable for suspended and surface-mounted installation. Suspended continuous line applications around corners is possible with node to be ordered separately.
Optical system
With highly efficient CDP microprisms. With direct and indirect light distribution in suspended-luminaire applications. Division of total light distribution (direct/indirect): 40% / 60%. In applications as a surface-mounted luminaire with predominantly direct light distribution with indirect component for ceiling illumination. Glare evaluation according to UGR rating (EN 12464-1) < 16. VDU workstation-compliant in accordance with 12464-1 Completely harmonious light effect due to homogeneously illuminated light emission.
LED system
LED system with angled LEDs positioned laterally to the light emission aperture and a chamber system for highly effective reflection and transfer of the light. Subsequent data regarding luminaire luminous flux and system connected load refer to operating the respective module as a surface-mounted luminaire. Rated luminous flux in suspended luminaire application 6200 lm, Rated luminous flux in surface-mounted luminaire application 5400 lm, connected load 41,00 W, Power Faktor ? > 0,95, luminous efficiency of luminaire 131 lm/W. Light colour neutral white, correlated colour temperature (CCT) 4000 K, general colour rendering index (CRI) Ra > 80. Colour locus tolerance (initial MacAdam) = 3 SDCM, Mean rated service life L90(tq 25 °C) = 50,000 h.
Luminaire body
Luminaire body of extruded aluminium profile. End caps of die-cast aluminium. Luminaire solvent-free powder-coated in silver-grey. (RAL 9006). Dimensions (L x W): 1490 mm x 240 mm, luminaire height 20 mm. Permissible ambient temperature (ta): -20 °C - +25 °C. Safety class (EN 61140): I, protection rating (DIN EN 60529): IP20, impact resistance level in accordance with IEC 62262: IK03, testing temperature of wire glow test in accordance with IEC 60695-2-11: 650 °C. Weight: 4,1 kg.
Versatile luminaire module for suspended and surface-mounted luminaires. In combination with accessories to be ordered separately, the modules are completed to form individual luminaires or continuous lines with continuous light emission surface for surface-mounted or suspended installation.
Applications
For the attractive lighting of offices, sales areas, exhibition spaces, banks, ticket halls, schools and educational facilities.
Mounting methods
In combination with the accessories to be ordered separately for the desired application, the module is suitable for suspended and surface-mounted installation. Suspended continuous line applications around corners is possible with node to be ordered separately.
Optical system
With highly efficient CDP microprisms. With direct and indirect light distribution in suspended-luminaire applications. Division of total light distribution (direct/indirect): 40% / 60%. In applications as a surface-mounted luminaire with predominantly direct light distribution with indirect component for ceiling illumination. Glare evaluation according to UGR rating (EN 12464-1) < 16. VDU workstation-compliant in accordance with 12464-1 Completely harmonious light effect due to homogeneously illuminated light emission.
LED system
LED system with angled LEDs positioned laterally to the light emission aperture and a chamber system for highly effective reflection and transfer of the light. Subsequent data regarding luminaire luminous flux and system connected load refer to operating the respective module as a surface-mounted luminaire. Rated luminous flux in suspended luminaire application 6200 lm, Rated luminous flux in surface-mounted luminaire application 5400 lm, connected load 41,00 W, Power Faktor ? > 0,95, luminous efficiency of luminaire 131 lm/W. Light colour neutral white, correlated colour temperature (CCT) 4000 K, general colour rendering index (CRI) Ra > 80. Colour locus tolerance (initial MacAdam) = 3 SDCM, Mean rated service life L90(tq 25 °C) = 50,000 h.
Luminaire body
Luminaire body of extruded aluminium profile. End caps of die-cast aluminium. Luminaire solvent-free powder-coated in silver-grey. (RAL 9006). Dimensions (L x W): 1490 mm x 240 mm, luminaire height 20 mm. Permissible ambient temperature (ta): -20 °C - +25 °C. Safety class (EN 61140): I, protection rating (DIN EN 60529): IP20, impact resistance level in accordance with IEC 62262: IK03, testing temperature of wire glow test in accordance with IEC 60695-2-11: 650 °C. Weight: 4,1 kg.
