New AMD EPYC™ Family of Processors - Same Great SP5 Platform The SP5 socket has reached its pinnacle form with 5th Generation AMD EPYC™ processors. The same successful platform that was shared by AMD EPYC™ 9004 & 8004 series processors is now the same one for AMD EPYC™ 9005 series processors. With up to 192 cores, increased frequencies and cache, this top tier performance platform targets general purpose, cloud native, and technical computing. Building on the advantages of the EPYC™ 9004 series, the new EPYC™ 9005 series adopts the 3nm process with AMD “Zen5” and “Zen5c” core architecture, excelling in both energy efficiency and cost optimization. GIGABYTE has already prepared for this new processor with new servers and updates to existing products for 4th Gen AMD EPYC™ processors.
Built-in processor
No
Motherboard chipset
AMD SoC
Processor socket
Socket SP5
Number of processors supported
1
Compatible processor series
AMD EPYC 9005, AMD EPYC 9004
Number of DIMM slots
24
Supported memory types
DDR5-SDRAM
Memory channels
Dodeca-channel
Number of storage drives supported
14
Hot-swap HDD bays
Yes
Number of 2.5" bays
12
Storage drive sizes supported
2.5,M.2
Supported storage drive types
HDD & SSD
Supported storage drive interfaces
Serial ATA, PCI Express 3.0, Serial Attached SCSI (SAS)-4
SSD form factor
M.2
On-board graphics card model
Aspeed AST2600
USB 2.0 ports quantity
0
Ethernet LAN (RJ-45) ports
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
Mini DisplayPorts quantity
1
PCI Express x16 (Gen 5.x) slots
3
Number of M.2 (M) slots
2
Trusted Platform Module (TPM)
Yes
Backplanes support
Yes
Chassis type
Rack (1U)
Product colour
Black, Steel
LED indicators
LAN, HDD, SSD, Status
On/off switch
Yes
Reset button
Yes
Cooling type
Active
Heat sink included
Yes
Number of fans
8 fan(s)
Fan diameter
4 cm
Power supply
2000 W
Number of main power supplies
2
Redundant power supply (RPS) support
Yes
Number of redundant power supplies supported
2
Number of redundant power supplies installed
2
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Input current
10 - 12 A
80 PLUS certification
80 PLUS Titanium
Operating temperature (T-T)
10 - 35 °C
Storage temperature (T-T)
40 - 60 °C
Operating relative humidity (H-H)
8 - 80%
Storage relative humidity (H-H)
20 - 95%
Width
438 mm
Depth
815 mm
Height
43.5 mm
Weight
13.5 kg
Packaging content
1 x R163-ZG2-AAJ2; 1 x CPU heatsink; 1 x Mini-DP to D-Sub cable; 1 x GPU power cable (12VHPWR, 400mm); 1 x 2-Section Rail kit
Package width
1043 mm
Package depth
594 mm
Package height
252 mm
Package weight
15.7 kg
