Housing material
Metal
International Protection (IP) code
IP66, IP67
Package width
54 mm
Package depth
92 mm
Package height
149 mm
Package weight
411 g
Compliance certificates
CE, RoHS, REACH
Control element type
Square roller lever
Ambient temperature range
25 - 85 °C
Degree of protection (NEMA)
12
Electrical connection type
Other
Suitable for safety functions
Yes
Number of NO contacts
1
Number of change-over contacts
0
Number of NC contacts
1
Sensor length
11.9 cm
Sensor width
5.6 cm
Sensor height
3.78 cm
Switching function
Quick-break switch
Number of safety auxiliary contacts
1
Rated operational current (Ie at DC-13, 24V)
3 A
Rated operational current (Ie at DC-13, 125V)
0.55 A
Rated operational current (Ie at AC-15, 24V)
6 A
Forced opening
Yes
Battery included
No
Latching switching function
No
Housing coating
Lacquered
Status indication
No
Rated operation current (Ie at AC-15, 125V)
6 A
The item is known under the following item numbers in our system
SKU:
SIE-10476758
EAN:
4011209693463
