You will receive 125 pieces of item 74901, packed in a plastic bag for protection against moisture and supplied in an outer carton.
Conductor material: Pure copper Cable construction: S/FTP (individual pair and overall shielding) Jacket material: TPE (LSZH – Low Smoke Zero Halogen) Wire gauge: AWG28 Operating temperature: -20 to +75 °C Outer diameter: 4.1 mm Pin assignment: 1:1 according to T568B PoE support: Yes, up to 87 Watts (4PPoE)
InLine Bulk ecoPacks are environmentally friendly bulk packaging solutions in which the products are packed together in a single PE bag for protection against moisture and supplied in a standard outer carton. The packaging quantity varies depending on the product size to ensure optimum carton utilization. InLine Bulk ecoPacks are especially suitable for direct use, for example for in-house requirements or on-site customer installations. You receive the proven InLine quality with minimal packaging. This saves time and money while protecting the environment.
More economical: Faster unpacking saves you time Ideal for customer installations More environmentally friendly: Less packaging - Less waste The cables are packed together in a single PE bag to protect them from moisture. Individual slip bags are eliminated. More efficient: The packaging unit is based on the optimum utilization of the carton capacity. Resources are used and utilized efficiently. More cost-effective: Price advantage through bulk purchasing 5% below the individual/standard price
Cable length
1 m
Cable standard
Cat6a
Cable shielding
S/FTP (S-STP)
Connector 1
RJ-45
Connector 2
RJ-45
Product colour
Grey
Connector 1 gender
Male
Connector 2 gender
Male
Cable shape
Round
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Connector contacts plating
Gold
Jacket material
Low smoke zero halogen (LSZH), Thermoplastic elastomer (TPE)
Conductor material
Copper
AWG wire size
28
Data transfer rate
10000 Mbit/s
Frequency
500 MHz
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) type supported
PoE+, PoE++ (4PPoE)
Molded cable boot
Yes
Operating temperature (T-T)
20 - 75 °C
Storage temperature (T-T)
20 - 75 °C
Compliance certificates
CE, REACH, RoHS
Width
15 mm
Depth
1000 mm
Height
12 mm
Outer diameter
4.5 mm
Weight
3.4 kg
Quantity per pack
125 pc(s)
Package width
190 mm
Package depth
280 mm
Package height
290 mm
Package weight
3.7 kg
Package volume
16000 cm³
Dimensions (WxDxH)
15 x 1000 x 12 mm
Sustainability compliance
Yes
