GST18i3 Tilslutningkabel 3P Hun/Fri HF 1,5mm² Sort 1M
Item no.: [4561145] | Manufacturer: WIELAND | Model no.: 92.232.1063.1 | EAN: 4015573664661 | EL-nr.: 7828406782
out of stock
The item is not in stock. More info
Udsolgt
Varen er ikke på lager.
Brug funktionen ”Giv mig besked..." herunder for opdateringer.
Delivery options - Select at checkout
Shipping @price - GLS
12,00
EUR
6,81
Incl. VAT 8,51
Total incl. delivery
23,51
Notify me when the item is in stock again
The function requires that you are logged in. Create a user and use our smart list system to keep track of future purchases, regular purchases or wish lists.
Create user
Login
Create user
Login
Send på mail
Cordsets
GST18 cordsets in a variety of combinations and lengths
1.5mm
2
flexible cable
Standards
DIN VDE 0628, EN/IEC 61535 (in draft).
Wieland GST Connector
The Wieland GST connector is a 18i3 series, female, 3-pole, cable assembly with a 1m cable and strain relief. It has an electric rating of 250V and 16A. These female connectors can be connected with the correct polarity, therefore, it provides security of clear segregation of different applications without having to remake any incorrect connections. Mechanical and colour coding provides for safe and easy separation of different applications, virtually eliminating miss mating errors.
Features and Benefits
A leading earth contact and an optional locking device all contribute to ensure the safest possible connections
Flexible cable
Free end with ultrasonically welded conductor ends
Insulation components continuous temperature is 100°C
Pollution degree 3
These connectors are then mutually compatible
Applications
Lighting and other factory assembled equipment
Switching application
Certifications
DIN
EN/IEC 61535
IP20C rated
IP40 rated
VDE 0470
VDE 0628
GST18 Compact Connectors
The GST18 is a pluggable device connector for use in lighting and other factory-assembled equipment. Mechanical and color coding provides for a safe and easy separation of different applications, virtually eliminating mis-mating errors. An IP20 touch-safe design, a leading earth contact and an optional locking device all contribute to ensure the safest possible connections.
