Black Box LB522A-KIT-R2, Network transmitter & receiver, 8400 m, 11.4 Mbit/s, 10,100 Mbit/s, Full, Half, 2000 entries
Item no.: [4746124] | Manufacturer: Black box | Model no.: LB522A-KIT-R2
out of stock
The item is not in stock. More info
Udsolgt
Varen er ikke på lager.
Brug funktionen ”Giv mig besked..." herunder for opdateringer.
Delivery options - Select at checkout
Shipping @price - GLS
12,00
EUR
1.770,82
Incl. VAT 2.213,53
Total incl. delivery
2.228,53
Notify me when the item is in stock again
Email:
Stock agent created. We will send an email when the item is in stock again.
The function requires that you are logged in. Create a user and use our smart list system to keep track of future purchases, regular purchases or wish lists. Create user Login
- Support QoS, CoS, and VLAN: Ensure mission-critical network connections are of top quality with advanced traffic management features. - A built-in console port makes setup a snap. And you can also use the embedded HTTP/SNMP agent to remotely manage the unit from anywhere in the world. - An advanced auto-rate algorithm automatically determines the best possible baud rate for each connection and sets up the extender without the need for user interface. - The unit has a built-in MDI-X switch, so it'll work with either a straight-through cable or a crossover cable. - Plug-and-play! Just plug it in, power it on, and it's up and running.
This kit includes a pair of auto-rate Ethernet extenders, using a standard 2-wire connection, which simplifies your life and provides cost-effective network extension by enabling you to make the most of your pre-existing twisted-pair infrastructure.
You'll be able to connect remote LANs across distances and at speeds previously unheard of. An auto-rate feature ensures that you achieve the highest possible speed on each connection.
It's easy to use, too. Plug-and-play means that you'll be up and running in seconds, and the built-in MDI-X works with either straight-through or crossover cables.
The pair autosenses the data rate up to 11.4 Mbps at a distance of 4750 feet (1450 m) to provide reliable broadband connectivity with full-duplex symmetric rates, with lower speeds at longer distances of up to about 5.2 miles (8.4 km).
Type
Network transmitter & receiver
Maximum transfer distance
8400 m
Data transfer rate
11.4 Mbit/s
Ethernet LAN data rates
10,100 Mbit/s
VLAN tagging
Yes
Duplex system
Full, Half
MAC address table
2000 entries
Firmware upgradeable
Yes
Cabling technology
10/100Base-T(X)
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Security algorithms
SNMP
Quality of Service (QoS) support
Yes
Web-based management
Yes
Ethernet LAN (RJ-45) ports
4
Product colour
Black
LED indicators
Alarm, Diagnostic, LAN, Link, Power, WAN
Certification
CE, FCC 15A; EMC 89/336/EEC; 73/23/EEC
AC input voltage
90 - 240 V
AC input frequency
50 - 60 Hz
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
40 - 85 °C
Width
195 mm
Depth
168 mm
Height
48 mm
Weight
1.3 kg
Compliance certificates
RoHS
