7PV15 - timer relay; on delay 7 time ranges Wide range input Change the time range during operation Change the functional operation in de-energised state High repeat accuracy Integrated overvoltage protection LED status display Slim design
Height
90 mm
Package width
82 mm
Package depth
93 mm
Package height
22 mm
Package weight
73 g
Compliance certificates
CE, RoHS, REACH
Timer duration (minimum)
0.05 s
Timer duration (maximum)
100 s
Actuating voltage type
AC/DC
Electrical connection type
Screw connection
Rated control supply voltage (DC)
12 - 240 V
Rated control supply voltage (AC 50Hz)
12 - 240 V
Rated control supply voltage (AC 60Hz)
12 - 240 V
Minimum order quantity
1 pc(s)
Battery included
No
Pluggable on auxiliary contact block
No
Semiconductor output
No
Function star-delta
No
Number of outputs (delayed, change-over contact)
1
Function floating contact on energization
No
Function delay on de-energization
No
Function floating contact on de-energization
No
Number of outputs (undelayed, normally open contact)
0
Function pulse shaping
No
Number of outputs (undelayed, normally closed contact)
0
Number of outputs (delayed, normally closed contact)
0
Number of outputs (undelayed, change-over contact)
0
Number of outputs (delayed, normally open contact)
0
Remote operation possible
No
Suitable as remote control
No
Function flashing (starting with pause, fixed time)
No
Function flashing (starting with pulse, fixed time)
No
Clock function (starting with pause, variable)
No
Clock function (starting with pulse, variable)
No
Outputs (reversible delayed/undelayed)
No
Maximum order quantity
1 pc(s)
The item is known under the following item numbers in our system
EAN:
4011209777286
SKU:
SIE-10482937
SKU:
7PV1538-1AW30
ELnr:
7823200585
