QNAP QGD-1600P, Managed, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting, 1U

Item no.: [5838703] | Manufacturer: Qnap Systems | Model no.: QGD-1600P-4G | EAN: 4713213516195

Remote stock (2-3 days)

The item is in a remote warehouse, delivery time is 2-3 business days. More info

Shipping @price - GLS

12,00

EUR 636,10

Incl. VAT 795,13

Total incl. delivery 810,13

Read further specifications and description

The QGD-1600P features SDN, enabling it to function as a NAS, NVR, router, firewall and AP controller for IP surveillance, network security, storage expansion, and wireless LAN management applications. Therefore, the Guardian series offers SMBs a cost-optimized and centrally managed LAN deployment solution.

Produktbeskrivelse	QNAP QGD-1600P - switch - 16 porte - smart - monterbar på stativ
Enhedstype	Switch - 16 porte - smart
Pakningstype	Monterbar på stativ
Undertype	Gigabit Ethernet
Porte	4 x 10/100/1000 (PoE++) + 10 x 10/100/1000 (PoE+) + 2 x kombination Gigabit SFP (PoE+)
Power Over Ethernet (PoE)	PoE++
PoE-budget	370 W
Præstation	Ikke-blokerende båndbredde: 16 Gbps Omkoblingskapacitet: 32 Gbps
MAC adresse table størrelse	8K indtastningshukommelse
Jumborammesupport	9KB
Protokol til fjernadministration	HTTP, CLI
Egenskaber	Datatransport, auto-negotiation, trunking, VLAN-understøttet, WOL, IGMP snooping, portspejling, ACL support, LACP support, LLDP support, DHCP klient, Energy Efficient Ethernet, løkkeforebyggelse, SDN, plan PoE, DNS-klient, portbaseret VLAN, portbaseret QoS, SNTP-klient, DSCP based QoS, PoE Detection
Overensstemmelsesstandarder	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt
Effekt	AC 120/230 V (50/60 Hz)
Vægt	4.41 kg
Systemkrav	UNIX, Linux, Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Apple MacOS X 10.7 eller senere, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 10, Microsoft Windows Server 2016
Producentgaranti	2 års garanti

Generelt
Enhedstype	Switch - 16 porte - smart
Pakningstype	Monterbar på stativ
Undertype	Gigabit Ethernet
Porte	4 x 10/100/1000 (PoE++) + 10 x 10/100/1000 (PoE+) + 2 x kombination Gigabit SFP (PoE+)
Power Over Ethernet (PoE)	PoE++
PoE-budget	370 W
Præstation	Ikke-blokerende båndbredde: 16 Gbps Omkoblingskapacitet: 32 Gbps
MAC adresse table størrelse	8K indtastningshukommelse
Jumborammesupport	9KB
Protokol til fjernadministration	HTTP, CLI
Krypterings algoritme	FIPS 140-2, 256-bit AES, AES-NI
Egenskaber	Datatransport, auto-negotiation, trunking, VLAN-understøttet, WOL, IGMP snooping, portspejling, ACL support, LACP support, LLDP support, DHCP klient, Energy Efficient Ethernet, løkkeforebyggelse, SDN, plan PoE, DNS-klient, portbaseret VLAN, portbaseret QoS, SNTP-klient, DSCP based QoS, PoE Detection
Overensstemmelsesstandarder	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt
Processor	1 x Intel Celeron: 1.8 GHz
RAM	4 GB (installeret) / 8 GB (maks.) - SO DIMM 260-PIN - DDR4 SDRAM
Flashhukommelse	4 GB
Indbygget udstyr	Status-LCD, 2 x 2,5" SATA 6Gb/s drevbåse
Statusindikatorer	PoE, link/aktivitet, hastighed
Ekspansion / Konnektivitet
Interface	4 x 1000Base-T RJ-45 PoE++ - 60 W 12 x 1000Base-T RJ-45 PoE+ - 30 W 2 x Gigabit LAN SFP 1 x HDMI output 2 x USB 2.0 Type A 1 x USB 3.0 Type A 1 x administration (LAN) RJ-45
Ekspansionsåbninger	2 (total) / 2 (fri) x PCI Express 2.0
Effekt
Strømenhed	Intern strømforsyning
Nødvendig spænding	AC 120/230 V (50/60 Hz)
Strømforbrug ved drift	418 watt
Diverse
Udstyr inkluderet	4 gummifødder, 6 x fladhovede skruer (til 2,5" HDD)
Medfølgende ledninger	1 x netværkskabel
Rackmonteringspakke	Inkluderet
Overensstemmelsesstandarder	VCCI, BSMI, FCC, RCM
Programmer / Systemkrav
Med software	QTS 4.4.1
OS nødvendig	UNIX, Linux, Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Apple MacOS X 10.7 eller senere, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 10, Microsoft Windows Server 2016
Mål og vægt
Vægt	4.41 kg
Mål & vægt (forsendelse)
Bredde ved forsendelse	52.8 cm
Dybde ved forsendelse	40.3 cm
Højde ved forsendelse	16 cm
Vægt ved forsendelse	5.56 kg
Producentgaranti
Service & Support	Begrænset garanti - 2 år
Miljømæssige parametre
Min. driftstemperatur	0 °C
Maks. driftstemperatur	45 °C
Fugtighedsgrad ved brug	5 - 95 % (ikke-kondenserende)

The item is known under the following item numbers in our system

SKU:	QGD-1600P-4G
EAN:	4713213516195

Why do I find that the same product is available on different item numbers?

Manufacturers often release the same product with different item numbers, typically just different versions of the packaging. For example, the packaging may be targeted at different countries. We try our best to unify the products, but it can happen that the same product appears on different item numbers in our system.
