One enclosure, many devices Elegant, slim enclosure is made of high quality plastic. Uniform appearance of all detectors installed in the premises makes it difficult for an intruder to identify the specific model used in the system because all of them look the same.
Reliable motion detection A unique lens Each detector comes with a modern lens designed and manufactured in Japan – specially for SATEL. It provides a very large detection area with dimensions up to 20 m x 24 m and 90° viewing angle.
New motion detection algorithm Many years of experience in the production of motion detectors and the use of the latest technologies made it possible to develop an advanced new generation algorithm of motion detection. Because of it, SLIM LINE detectors ensure reliable detection of intruders throughout the entire monitored area, without triggering unwanted alarms.
Digital temperature compensation SLIM LINE detectors dynamically adjust the motion detection algorithm to changes in ambient temperature, so these changes do not affect the effectiveness of the detectors.
Quick lens replacement As you can easily replace the complete front part with the lens, the SLIM LINE detectors* can be quickly and conveniently customized to suit the needs of the premises, e.g. to the shape of protected room. The wide-angle (WD) lenses are fitted as standard, but curtain (CT) and long-range (LR) lenses are also optionally available.
DUAL – two detection Dual technology detectors, in addition to the infrared (PIR) detector, are also fitted with a microwave sensor (MW), which obviously enhances their immunity to unwanted alarms caused by rapid temperature changes in the protected room or movements of air masses within the coverage area.
Creep zone protection An integrated tilting mirror used in the LUNA* and PRO models enables effective monitoring of the so-called creep zone, i.e. the area directly under the detector.
Signaling covering attempts The SLIM LINE detectors in the PRO version come with the function of active anti-masking using infrared radiation. Therefore, any attempts to disable them, for example, by covering the lens with adhesive tape or spraying paint or clear varnish on it, can be signaled.
Mounting type
Ceiling/wall
LED indicators
Yes
Product colour
White
Installation height (max)
2.4 m
Detection angle
90°
Housing material
Plastic
Remote control included
Yes
Protection class
II
Sensor type
Passive infrared (PIR) sensor
Connectivity technology
Wired
Detection distance
24 m
Power consumption
100 mA
Standby current
14 mA
Battery voltage
12 V
Operating temperature (T-T)
10 - 55 °C
Width
62 mm
Depth
42 mm
Height
137 mm
Weight
144 g
