LANCOM XS-5116QF, Managed, L2/L3, 10G Ethernet (100/1000/10000), Rack mounting, 1U

Item no.: [6494930] | Manufacturer: Lancom Systems | Model no.: 61859 | EAN: 4044144618598

Remote stock (2-3 days)

The item is in a remote warehouse, delivery time is 2-3 business days. More info

Shipping @price - GLS

12,00

EUR 4.857,07

Incl. VAT 6.071,34

Total incl. delivery 6.086,34

Read further specifications and description

This 10G aggregation switch offers future-proof fiber-optics performance and acts as a superordinated instance in distributed networks and provides high-performance 14 SFP+ ports for aggregating access switches and further 2 QSFP+ ports. Professional redundancy functionalities and two hot-swappable power supplies guarantee fail-safe operations. Thanks to the holistic LANCOM network management the device can be configured dynamically and automatically via the LANCOM Management Cloud or via cloud-enabled web GUI, and even via cloud-enabled CLI.

Produktbeskrivelse	LANCOM XS-5116QF - switch - 16 porte - Administreret - monterbar på stativ
Enhedstype	Switch - 16 porte - L3 - Administreret - kan stables
Pakningstype	Front til ryg-luftstrøm monterbar på stativ 1U
Undertype	10 Gigabit Ethernet
Porte	12 x 1 Gigabit / 10 Gigabit SFP+ + 2 x kombo 1/2.5/5/10 Gigabit Ethernet / 1/10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ (uplink/stabling)
Præstation	Forsinkelse: 4 µs Bagplanshastighed: 440 Gbps Gennemløb (64-byte pakkestørrelse): 327 Mpps
Kapacitet	Taggede VLANs: 4096 Aktive VLANer: 4000 IGMP multicast-grupper: 1024
MAC adresse table størrelse	32K indtastningshukommelse
Jumborammesupport	12.000 byte
Routingprotokol	IGMPv2, IGMP, IGMPv3, statisk IPv4 routing, statisk IPv6 routing, police-baseret routing (PBR), MLDv2, MLD
Protokol til fjernadministration	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, SCP, ICMP, DHCP
Egenskaber	Datatransport, routing, VLAN-understøttet, IGMP snooping, gem og send, Broadcast Storm Control, IPv6 understøttet, Multicast Storm Control, Unicast Storm Control, firmware kan opgraderes, SNTP-understøttet, STP support, RSTP support, MSTP support, proritets-baseret flow kontrol, DHCP snooping, ACL support, QoS, RADIUS support, SSH support, DHCP server, MDL snooping, DAI, nulstillingsknap, Cable Diagnostics Function, UDLD, IPv4 support, LACP support, LLDP support, DHCP videresendelse, LACP, Port Security, DHCP klient, statisk routing, FEC, hot swappable blæser, CoS, mærket VLAN, sFlow v5, GVRP, IGMP proxy, PTP, 2 blæsere, Storm Control, IP-kildebekyttelse, SCP, MIB II, IF MIB, politikbaseret routing, AAA, IGMP-forespørger, Voice VLAN, PVE, Guest VLAN, DoS protection, sikkerhedsstøvle, ARP spoofing, SD-LAN support
Overensstemmelsesstandarder	IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1as, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1Qbb, IEEE 1588v2, IEEE 802.1Qat, IEEE 802.3bj, IEEE 802.1Qav
Effekt	AC 120/230 V (50/60 Hz)
Overskudsspænding	Valgfri
Dimensioner (B x D x H)	44.2 cm x 37.5 cm x 4.4 cm
Vægt	4.9 kg
Producentgaranti	5 års garanti

Generelt
Enhedstype	Switch - 16 porte - L3 - Administreret - kan stables
Pakningstype	Front til ryg-luftstrøm monterbar på stativ 1U
Undertype	10 Gigabit Ethernet
Porte	12 x 1 Gigabit / 10 Gigabit SFP+ + 2 x kombo 1/2.5/5/10 Gigabit Ethernet / 1/10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ (uplink/stabling)
Præstation	Forsinkelse: 4 µs Bagplanshastighed: 440 Gbps Gennemløb (64-byte pakkestørrelse): 327 Mpps
Kapacitet	Taggede VLANs: 4096 Aktive VLANer: 4000 IGMP multicast-grupper: 1024
MAC adresse table størrelse	32K indtastningshukommelse
Jumborammesupport	12.000 byte
Routingprotokol	IGMPv2, IGMP, IGMPv3, statisk IPv4 routing, statisk IPv6 routing, police-baseret routing (PBR), MLDv2, MLD
Protokol til fjernadministration	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, SCP, ICMP, DHCP
Krypterings algoritme	MD5, SSL
Autentificeringsmetode	Secure Shell (SSH), RADIUS, TACACS+
Egenskaber	Datatransport, routing, VLAN-understøttet, IGMP snooping, gem og send, Broadcast Storm Control, IPv6 understøttet, Multicast Storm Control, Unicast Storm Control, firmware kan opgraderes, SNTP-understøttet, STP support, RSTP support, MSTP support, proritets-baseret flow kontrol, DHCP snooping, ACL support, QoS, RADIUS support, SSH support, DHCP server, MDL snooping, DAI, nulstillingsknap, Cable Diagnostics Function, UDLD, IPv4 support, LACP support, LLDP support, DHCP videresendelse, LACP, Port Security, DHCP klient, statisk routing, FEC, hot swappable blæser, CoS, mærket VLAN, sFlow v5, GVRP, IGMP proxy, PTP, 2 blæsere, Storm Control, IP-kildebekyttelse, SCP, MIB II, IF MIB, politikbaseret routing, AAA, IGMP-forespørger, Voice VLAN, PVE, Guest VLAN, DoS protection, sikkerhedsstøvle, ARP spoofing, SD-LAN support
Overensstemmelsesstandarder	IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1as, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1Qbb, IEEE 1588v2, IEEE 802.1Qat, IEEE 802.3bj, IEEE 802.1Qav
Statusindikatorer	System, link/aktivitet, blæser, stabel
Ekspansion / Konnektivitet
Interface	12 x 1/10Gbit LAN SFP+ 2 x 1/2.5/5/10GBase-T RJ-45 1 x administration (mikro-USB) konsol 1 x administration (RS-232) RJ-45 konsol 1 x USB Type A 2 x 40 Gbit LAN QSFP+ uplink/stacking
Effekt
Strømenhed	Intern strømforsyning - hot-plug
Antal installeret	1
Maks. antal understøttet	2
Overskudsspænding	Valgfri
Skema til overskudsspænding	1+1 (med valgfrit netaggregat)
Nødvendig spænding	AC 120/230 V (50/60 Hz)
Diverse
Udstyr inkluderet	2 x 19" monteringsbøjler
Medfølgende ledninger	1 x serielt kabel - 1.5 m 1 x micro-USB kabel - 1 m
Rackmonteringspakke	Inkluderet
Overensstemmelsesstandarder	EN55024, FCC CFR47 Part 15 A, EN 62368-1, EN 55032
Mål og vægt
Bredde	44.2 cm
Dybde	37.5 cm
Højde	4.4 cm
Vægt	4.9 kg
Producentgaranti
Service & Support	Begrænset garanti - 5 år
Miljømæssige parametre
Min. driftstemperatur	0 °C
Maks. driftstemperatur	40 °C
Fugtighedsgrad ved brug	10 - 90 % (ikke-kondenserende)

The item is known under the following item numbers in our system

EAN:	4044144618598
EAN:	4044144648595
SKU:	LAN-61859
SKU:	NON-2205059

Why do I find that the same product is available on different item numbers?

Manufacturers often release the same product with different item numbers, typically just different versions of the packaging. For example, the packaging may be targeted at different countries. We try our best to unify the products, but it can happen that the same product appears on different item numbers in our system.
