Indicator light, 16 mm, round, plastic, clear, Lampholder W2 x 4.6 d, with incandescent lamp 24 V Indicator lights SIRIUS 3SB2 for signaling switching statuses or faults in systems. The industry-standard 3SB2 pushbuttons and indicator lights have a modular design and are proven in practice. Thanks to their compact design, they are particularly suitable for small control panels. They are extremely functional and rugged, and comply with the IEC/EN 60947-5-1 and 60947-5-5 standards. They can be installed with a high packing density and without the need for any special tools. Versions available: Several colors, different voltage variants. Note: Complete unit, supplied with holder and contact block(s). 3SB2 - Space-saving, proven in practice and industry standard!
International Protection (IP) code
IP65
Front ring
No
Base type
W2 x 4.6
Package weight
21 g
Package depth
72 mm
Package width
50 mm
Package height
50 mm
Compliance certificates
CE, RoHS
Voltage type
AC/DC
Electrical connection type
Flat plug-in connection
Hole diameter
1.6 cm
Rated operating voltage (Ue)
5 - 60 V
Battery included
No
Installation opening width
1.9 cm
Installation opening height
9 mm
With light source
Yes
Minimum order quantity
1 pc(s)
Maximum order quantity
1 pc(s)
The item is known under the following item numbers in our system
EAN:
4011209093928
SKU:
3SB22246BH06
