Cambium Networks cnPilot e501S, 2.4 GHz, 5 GHz, 867 Mbit/s, 802.1x RADIUS, EAP-AKA, EAP-FAST, EAP-GTC, EAP-SIM, EAP-TLS, EAP-TTLS, WPA-PSK, WPA-TKIP,..., 10,100,1000 Mbit/s

Item no.: [7477419] | Manufacturer: Cambium Networks | Model no.: PL-501S000A-EU | EAN: 5704174278030

Remote stock (2-3 days)

The item is in a remote warehouse, delivery time is 2-3 business days. More info

Shipping @price - GLS

12,00

EUR 873,14

Incl. VAT 1.091,43

Total incl. delivery 1.106,43

Read further specifications and description

The cnPilot™ e501S 802.11ac Outdoor Sector Access Point includes an IP67 enclosure, 90° ~ 120° integrated sector antenna, supports 256 client associations, 16 SSIDs, WPA-2 encryption, Dynamic VLANs, DFS channels, Access Control Lists (ACL), and more.

Produktbeskrivelse	Cambium Networks cnPilot E501S - trådløs forbindelse - udendørs - Wi-Fi 5 - cloud-administreret
Enhedstype	Trådløs forbindelse
Formfaktor	Væg/pælmonterbar - udendørs
Lokalisering	Europa
Dataforbindelsesprotokol	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Frekvensbånd	2.4 GHz, 5 GHz
Præstation	Maksimum datahastighed (2,4 GHz): 300 Mbps Maksimum datahastighed (5 GHz): 867 Mbps
Kapacitet	Samtidige brugere: 256 SSID'er per radio: 16 VLANs understøttet: 4096
Udstyr inkluderet	Vippebøjle
Power Over Ethernet (PoE) understøttet	PoE
Dimensioner (B x D x H)	20.4 cm x 6.5 cm x 30 cm
Vægt	881 g
Producentgaranti	3 års garanti

Generelt
Enhedstype	Trådløs forbindelse
Robust design til udendørsbrug	Udendørs
Bredde	20.4 cm
Dybde	6.5 cm
Højde	30 cm
Vægt	881 g
Lokalisering	Europa
Netværk
Model	Væg/pælmonterbar
Forbindelsesteknologi	Trådløs
Liniekodningsformat	CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM
Dataforbindelsesprotokol	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Spread-spectrum metode	OFDM, DSSS
Netværks/overføselsprotokol	NTP, PPPoE, DHCP, DNS, L2TPv2, HTTP, HTTPs
Routingprotokol	IGMPv2, IGMP
Protokol til fjernadministration	SNMP 1, SNMP 2, Telnet, SNMP 3, SSH, NTP, Syslog
Cloud-administreret	Ja
Frekvensbånd	2.4 GHz, 5 GHz
Præstation	Maksimum datahastighed (2,4 GHz): 300 Mbps Maksimum datahastighed (5 GHz): 867 Mbps
Kapacitet	Samtidige brugere: 256 SSID'er per radio: 16 VLANs understøttet: 4096
Egenskaber	Firewallbeskyttelse, aktivitet, Mesh networking, Wireless Intrusion Detection System (WIDS), Wi-Fi Multimedia (WMM) support, Auto Channel Select (ACS), Quality of Service (QoS), DHCP server, LLDP support, DHCP videresendelse, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), SNMP fælde, GRE tunneling, dobbelt-stream (2x2), Captive Portal, sikkerhedslåseåbning (kabellås solgt separat), pakkesammenlægning A-MPDU, pakkesammenlægning A-MSDU, båndstyring, Airtime Fairness, Denial of Service (DoS) protection, STBC-support, opportunistisk nøgle-caching (OKC), 2x2 SU-MIMO-teknologi, MIMO Power Save, HotSpot 2.0, RESTful APIs, cnMaestro support, VLAN-pooling, Passpoint Release 2, plan til/fra, DSCP/ToS mapping, forbedret roaming med grænseværdier, send bomstyring
Krypterings algoritme	AES, TKIP, WPA2, WPA-PSK, WPA2-Enterprise
Autentificeringsmetode	RADIUS, MS-CHAP v.2, EAP-FAST, EAP-SIM, EAP-AKA, MACAuth, EAP-TLS, EAP-TTLS, EAP-PEAP, PEAPv0, PEAPv1
Overensstemmelsesstandarder	IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.3at, IEEE 802.11ac, IEEE 802.11w, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v
Antenne
Antenne	Intern
Forstærkning	13 dBi
Ekspansion / Konnektivitet
Interface	1 x 1000Base-T - RJ-45 1 x 1000Base-T (PoE) - RJ-45 - 15.4 W
Diverse
Udstyr inkluderet	Vippebøjle
Overensstemmelsesstandarder	ETSI, IEC 60950, UL 2043, FCC, EN 60601-1-2, IP67
Effekt
Power Over Ethernet (PoE) understøttet	PoE
Producentgaranti
Service & Support	Begrænset garanti - 3 år
Miljømæssige parametre
Min. driftstemperatur	-30 °C
Maks. driftstemperatur	60 °C
Fugtighedsgrad ved brug	95% RH (non-condensing)
