Audiocodes MediaPack 124 Analog VoIP Gateway,16 FXS, SIP Package for indoor deployments, AC-powered
Item no.: [7478335] | Manufacturer: AudioCodes | Model no.: MP124/16S/AC/SIP
out of stock
The item is not in stock. More info
Udsolgt
Varen er ikke på lager.
Brug funktionen ”Giv mig besked..." herunder for opdateringer.
Delivery options - Select at checkout
Shipping @price - GLS
12,00
EUR
965,59
Incl. VAT 1.206,99
Total incl. delivery
1.221,99
Notify me when the item is in stock again
Email:
Stock agent created. We will send an email when the item is in stock again.
The function requires that you are logged in. Create a user and use our smart list system to keep track of future purchases, regular purchases or wish lists. Create user Login
AudioCodes’ MediaPack 1xx series of Analog VoIP Gateways are cost-effective, stand-alone VoIP gateways that provide superior voice technology for connecting legacy telephones, fax machines and PBX systems with IP telephony networks and IP-based PBX systems. The MediaPack 1xx series gateways support a wide variety of service provider and enterprise applications:
- Service providers can use MediaPack gateways to connect Multi-Tenant Units (MTUs), IP Centrex subscribers, payphones, and rural users over wireless and satellite links - Enterprises can use MediaPack gateways to connect their legacy PBX systems over an IP infrastructure. In addition, in IP Centrex and central IP-PBX applications, MediaPack enhances remote location availability and provides Stand Alone Survivability (SAS) when there is no IP connection between branch locations and a central SIP server, SIP proxy or central IP-PBX
The MediaPack 1xx gateways are fully interoperable with leading softswitches, SIP servers and H.323 systems.
Features
- Support for 2 to 24 analog ports - T.38 fax compliant - Rich subscriber feature set: 3-way conference with local mixing, call pickup, hunt groups, call forwarding, call hold and call transfer - Echo cancellation, jitter buffer, voice activity detection (VAD) and comfort noise generation (CNG) - Complies with MGCP, H.323v4 and SIP control protocols
Benefits
- Leverage investment in existing analog telephone, modem, and fax systems – easing VoIP migration - Lifeline for fallback to PSTN for E911 (Emergency number PSTN breakthrough) or upon network/power failure (FXO and/or FXS configurations) - Standalone Survivability (SAS) keeps your business running in the event of a network failure
Produktbeskrivelse
AudioCodes MediaPack Series MP-124 - VoIP-gateway
Enhedstype
VoIP-gateway
Formfaktor
Ekstern
Antal porte
16
Dataforbindelsesprotokol
Ethernet, Fast Ethernet
VoIP-protokoller
SIP, MGCP
Grænseflader til telefoni
16 telefoner (FXS)
Effekt
AC 120/230 V (50/60 Hz)
Dimensioner (B x D x H)
44.5 cm x 26.6 cm x 4.4 cm
Vægt
1.8 kg
Generelt
Enhedstype
VoIP-gateway
Bredde
44.5 cm
Dybde
26.6 cm
Højde
4.4 cm
Vægt
1.8 kg
Netværk
Model
Ekstern
Antal porte
16
Forbindelsesteknologi
Kablet
Dataforbindelsesprotokol
Ethernet, Fast Ethernet
Netværks/overføselsprotokol
RTCP, RTP, BOOTP, DHCP, IPSec
Protokol til fjernadministration
TFTP, CLI, HTTPS, SNMP 3, HTTP, TR-069
Egenskaber
DiffServ understøttet, Type of Service (ToS), mærket VLAN, Trivial File Transfer Protocol (TFTP) support, DHCP-understøttelse, understøttet af BOOTP, håndterbar, Access Control List (ACL) support, Data prioritering (QoS) for VoIP-applikationer
Krypterings algoritme
TLS
Overensstemmelsesstandarder
IEEE 802.1Q, IEEE 802.1p
IP-telefoni
VoIP-protokoller
SIP, MGCP
Voice Codecs
T.38, G.711, G.723.1, G.726, G.727, G.729ab
Grænseflader til telefoni
16 telefoner (FXS)
IP-telefonifunktioner
Comfort noise generation (CNG), detektering af stemme (voice activity detection = VAD), echo cancellation (G.168) (eliminerer ekko), adaptative jitter buffer, samtaleparkering, overførsel af samtale, Id af kaldende nummer, automatisk fax/modem detektion og pass-through, DTMF generation/detection, besked venter
Ekspansion / Konnektivitet
Interface
1 x 100Base-TX - RJ-45 16 x FXS 1 x management (RS-232)
Diverse
Overensstemmelsesstandarder
VCCI Class B ITE, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class B, EN 60950-1, FCC CFR47 Part 15 B, TBR21, TIA/EIA/IS-968, ETSI
Effekt
Strømenhed
Intern strømforsyning
Nødvendig spænding
AC 120/230 V (50/60 Hz)
Miljømæssige parametre
Min. driftstemperatur
5 °C
Maks. driftstemperatur
40 °C
Fugtighedsgrad ved brug
10 - 90 % (ikke-kondenserende)
